HI-INC-SR
LoRaWAN IOT Tri-Axis Inclinometer Sensor
Scalable Measuring Range (±10° and ±90°)
APPLICATIONS
Land surveying
Structural Health Monitoring
Test and Measurement
Railway Sleepers Monitoring
Included Free Software
Satevis® LoRaWAN
«Free Software »
Overview
«Blue line »
Inclinometer technology
Accurate and low power MEMS technology
Scalable Measuring Range
user-seletctable range ±10° or ±90°, with  automatic range adjustment depending on the application
Sensor resolution
0.003°
Noise density
for ±10° range : 0.0007 °/√Hz on Y Axis, 0.008 °/√Hz on X, Z Axis
for ±90° range : 0.0012 °/√Hz on all axis
Sensor precision (full scale, @ 25°C, Static Measurement Mode every 2s)
±0.005° for  ±10° measurement range
±0.009° for  ±90° measurement range
Temperature Range
-40°C to +75°C
Maximum Radio Range
500 m in Line-Of-Sight
30-100 m in Non-Line-of-Sight
IP | NEMA Rating
IP65 | Nema 6
Casing
ABS UL94V-0
Dimensions in mm (LxWxH): 100 x 75 x 38 (without Radome antennas)
Weight (with internal battery) :
225g (screw mounting)
Integrated battery charger
Integrated Lithium-ion battery charger with high precision battery monitoring :
Overvoltage/Overcurrent/Short-Circuit/Undervoltage protection
Battery Temperature monitoring
Video
«Blue line »
Featured Video
Mechanical Mounting Options Video
Product Video
Download Ressources
«Blue line »
Step File
Datasheet
Exemple of Log Files
Selection Guide
Presentation SR Sub Series Users
IOT Inclinometer Sensor Repeatbility Test Report
Quick Start
User Manual
Drawing
